C95 Series SMS-TORK - Pulse Valve Timer

The C95 Series is an SMS-TORK microprocessor-based pulse valve timer that sequences the cleaning pulses on a jet-blast filter bank, firing each PL-series or PX-series solenoid valve in turn to keep dust from spreading into the surrounding area.

Housed in a 250 x 300 x 170 mm polyester enclosure for wall or panel mounting, the C95 is offered in output configurations from 8 up to 32 relay outputs (C95, C95.08, C95.16, C95.24 and C95.32) to match the number of pulse valves on a filter bank, with connection cables entering through a cable cover and terminating at screw terminals on the underside of the unit. It is specified in glass, cement, paint, fertilizer and animal feed plants wherever a dust filter bag bank needs to be cleaned on a repeating cycle, and complies with the Pressure Equipment Directive 97/23/EC and the Low Voltage Directive 2006/95/EEC.
