ifm AL1000 IO-Link Master with PROFINET Interface, 8 Port IP67

The ifm AL1000 is an IP67-rated IO-Link master with a PROFINET interface, giving 8 configurable IO-Link ports (4 Class A and 4 Class B) for field-mounted sensor and actuator integration without a control cabinet.

It runs from 19 to 31.2V DC with a separate actuator supply rated 1.6A per port and sensor supply rated 0.2A per port, communicates over a 10/100 MBaud PROFINET Ethernet interface at IO-Link revision 1.1, and is rated IP65/IP67 for -25 to 60 degrees C ambient with 30g shock and 5g vibration resistance.
