ifm AC2034 AS-Interface Universal Module, 4 Digital Outputs

The ifm AC2034 (EEMS/Module/4DO/T/CCT) is an AS-Interface universal module providing 4 PNP digital outputs for actuator control, built around the FC-E/SC lower-part mounting system used across the ifm AS-i module range.

It runs from 26.5 to 31.6V DC, draws under 60mA quiescent, supports up to 1000mA per output with a 4A total load limit, includes short-circuit protection and electrical isolation, and is rated IP65 for -25 to 60 degrees C ambient operation.
