Hager CDC463M RCCB, 4P 63A 30mA Type AC

The Hager CDC463M is a 4-pole pure residual current circuit breaker rated 63A with 30mA Type AC sensitivity, used as main or sub-main earth fault protection on 3-phase distribution boards.

It is rated 10kA conditional short-circuit current Inc per EN 61008-1, a making and breaking capacity of 0.63kA, rated operational voltage 230 to 400V, maximum operating voltage 440V, insulation voltage 500V, impulse withstand 4000V, in a 4-module, IP20 enclosure suitable for DIN rail mounting with screw terminals for 1 to 25 square mm conductors.
