Hager AEM432T RCBO, 3P+N 32A C Curve 30mA Type A

The Hager AEM432T is a 4-pole (3P+N) RCBO sized for 3-phase sub-circuits, rated 32A on a C curve with 30mA Type A residual current protection, bringing combined overcurrent and earth fault protection to a single device.

It is rated 6kA breaking capacity Icn per IEC 60898-1, rated operational voltage 230 to 415V, insulation voltage 500V, impulse withstand 4000V, overvoltage category III, with an electrical endurance of 2000 cycles and 4000 mechanical operations, in a 4-module enclosure rated IP2X, suitable for standard DIN rail mounting.
