Moxa PTC-101-S-SC-HV Ethernet-to-Fiber Media Converter

The Moxa PTC-101-S-SC-HV is an industrial Ethernet-to-fiber media converter that bridges a 10/100BaseT(X) copper port to a single-mode 100BaseFX SC fiber port, compliant with the mandatory sections of IEC 61850-3 for power substation automation environments.

It supports auto-negotiation, auto-MDI/MDI-X and Link Fault Pass-Through, runs from a wide 100 to 240VAC/VDC (HV) power input with a built-in high-reliability power supply, reaches a typical distance of 40km over single-mode fiber (1310nm, 29dB link budget), is housed in a metal DIN-rail-mount enclosure, and operates across -40 to 85 degrees C.
