Schneider Electric Altivar Process ATV980 Regenerative Drive System, 160 kW

The Schneider Electric Altivar Process ATV980 Regenerative System (ATV980C16Q4X1) is a pre-engineered enclosed regenerative drive system in a PanelSeT SFN enclosure with a graphical operating panel in the door, rated 160kW (normal duty) / 132kW (heavy duty) at 380-415V, capable of feeding braking energy back to the mains.

It delivers a continuous output current of 302A (normal duty) / 250A (heavy duty), an output frequency range of 0.1 to 599Hz, 96.5% energy efficiency, EtherNet/IP and Modbus TCP/serial communication, STO SIL 3 safety, an integrated EMC filter, and a 50kA/100ms prospective line short-circuit rating, in an IP23 enclosure.
