E40S6-100-3-T-5 Autonics - Shaft Rotary Encoder, 100 PPR

The E40S6-100-3-T-5 is an Autonics E40S Series solid-shaft incremental rotary encoder outputting 100 pulses per revolution, coupled to the driven shaft via a flexible coupling rather than the hollow bore of the E40H variants.

It runs on a 5 VDC (plus or minus 5 percent) supply, is rated IP50, withstands 50G shock and 1mm double-amplitude vibration at 10-55 Hz, and operates across -10 to 70 degrees C with a radial or connector-type cable, AWG24 5-wire shielded.
